24 Fibers Single mode MPO Trunk Cable

Regular Price: $46.53

Availability: In Stock

Total Length *

Fiber Distribution *

Polarity *

Connector 1 *

Connector 2 *

Buy it now with regular price.
  • High Quality MPO connector from Japan
  • Corning fiber inside
  • 3 year warranty

Product Specification

Weight 35 g
Connector Type

MPO-MPO

 Fiber Mode

Single mode
Fiber Count

24 Fibers

 Insertion Loss

0.7dB/0.35dB
Return Loss

≥20dB

 Polish Type

APC-APC
Cable Jacket

LSZH

 Jacket OD

3.0mm
Installation Tensile Load

100 N

 Long-Term Tensile Load

50 N
Mini Bend Radius

7.5mm

 Storage Temperature

-40°C to +85°C
Operating Temperature

-10°C to +70°C
Connector Type

MPO-MPO
Fiber Mode

Single mode
Fiber Count

24 Fibers
Insertion Loss

0.7dB/0.35dB
Return Loss

≥20dB
Polish Type

APC-APC
Cable Jacket

LSZH
Jacket OD

3.0mm
Installation Tensile Load

100 N
Long-Term Tensile Load

50 N
Mini Bend Radius

7.5mm
Storage Temperature

-40°C to +85°C
Operating Temperature

-10°C to +70°C

Features

  • Low Insertion Loss and Back Reflection Loss
  • Good Enchangeability
  • Good Durability
  • High Temperature Stability

    • Applications

  • High Density Wiring System
  • Wiring in Communication Base Station and Distribution Case
  • Jumper Connection
  • 40G and 100G System, QSFP Module
  • Optical Fiber Communication System, CATV
  • LANs and WANs
  • FTTP
    • Multi-fiber Push On, Compact and Superior Design
    Easy to Connect and Distribute
    Protective Dust Cap
