Description
| Features | Applications |
|
|
Performance Specifications
| Parameter | P Grade | A Grade | |
| Configuration | Port 1 to Port 2 to Port 3 | ||
| Operation Wavelength (nm) | 1310,1550 | ||
| Insertion Loss (dB) | Typical | 0.6 | 0.8 |
| Maximum | 0.8 | 1.0 | |
| Channel Peak Isolation (dB) | 50 | ||
| Channel Minimum Isolation (dB) | 40 | ||
| Channel Cross Talk (dB) | >50 | ||
| Polarization Dependent Loss (dB) | <0.15 | ||
| Polarization Mode Dispersion (ps) | <0.1 | ||
| Return Loss (dB) | >50 | ||
| Maximum Power Handling (mW) | 300 | ||
| Operating Temperature (°C) | 0 ~+70 | ||
| Storage Temperature (°C) | -40 ~+85 | ||
| Package Dimension (mm) | OD5.5 x L50 | ||
**Specifications may change without notice
