Description
|
Features
|
Applications
|
|
|
Performance Specifications
| Parameters | Values | |
| Center Wavelength(nm) | 1060 | 1550 |
| Operating Wavelength Range(nm) | ±30 | ±50 |
| Min. Transmission (%) | 93 | |
| Beam Diameter(mm) | 5.0+/-0.5,7.5+/-0.5 | |
| Ellipticity(%) | >95 | |
| Far Filed Divergence(1064nm)(mrad) | 0.5 | |
| Min. Return Loss (dB) | 35 | |
| Max.Optical Power(W) | 300 500 1000 | |
| Fiber Type | 25/250 DCF fiber,20/400 DCF Fiber or other | |
| Tensile Load (KG) | 2 | |
| Armoured Length(A)(m) | 2 5 | |
| Fiber Length(B) (m) | 2 | |
| Operating Temperature(℃) | -5 to +65 | |
| Storage Temperature(℃) | -40 to +85 | |
| Package Dimensions(mm) | Dia14.0X150.0 | |
* Above specification may change without notice.
Package Dimension
