Description
|
Features
|
Applications
|
|
|
Performance Specifications
| Parameters | Values |
| Central Wavelength(nm) | 1064 |
| Operating Wavelength Range(nm) | ±10 |
| Typ. Peak Isolation(dB) | 35 |
| Min. Isolation in Band (at 25℃) (dB) | 30 |
| Min. Transmission (%) | 90 |
| Nominal Output Beam Diameter(mm) | 7±1 |
| Min. Return Loss(Db) | 50 |
| Max. Optical Power (CW)(W) | 5,10, or Specify |
| Max. Peak Power(kW) | 5,10 |
| Fiber Type | LMA-GDF-10/125 , LMA-GDF-20/125, LMA-GDF-25/250 or Specify |
| Fiber Length(m) | >2.5 or Specify |
| Armored Length(m) | 2.0 or Specify |
| Tensile Load(kg) | 1 |
| Operation Temperature(℃) | 0 ~ +50 |
| Storage Temperature Range(℃) | -20 ~ +75 |
* Above specification are for device without connector, and may change without notice.
Package Dimension
