1064nm Faraday Mirror

Availability: In Stock

Fiber Diameter *

Fiber Length *

Connector *

Tag:

Description

Features Applications
  • High isolation
  • Low insertion loss
  • Excellent stability and reliability
  • Fiber laser
  • Fiber amplifier


Performance Specifications

Parameter Faraday Mirror
Operating Wavelength(nm) 1064
Bandwidth (nm) ±5
Typ. Insertion Loss(dB)@23℃ 2.6
Insertion Loss(dB) ≤3.0
Rotation Angle(degree) 45±3
Fiber Type HI1060 Fiber
Optical Power (CW) (mW) ≤200
Operating temperature(℃) -5~+70
Storage temperature(℃) -40~+85
Dimension (mm) Φ5.5×L17

*Above specifications are for device without connector.

*For devices with connectors, IL will be 0.5dB higher, RL will be 5dB lower.
